Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: H5120NL
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Specifications: |
H5120NL |
P/N: |
LP82453NLE |
Measure: |
L17.53XB12.19XH5.71 (mm) |
Mounting: |
SMD |
Ethernet: |
1x10/100/1000Base-Tx |
Samples: |
Free |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
Specifications: |
H5120NL |
P/N: |
LP82453NLE |
Measure: |
L17.53XB12.19XH5.71 (mm) |
Mounting: |
SMD |
Ethernet: |
1x10/100/1000Base-Tx |
Samples: |
Free |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
| Product Category: | Transformers Audio & Signal |
| Specifications | H5120NL / MDL SIN 1GD SM TU Low Profile Transformer |
| RoHS: | Details |
| Termination Style: | SMD/SMT |
| Inductance: | 350 uH |
| Primary Impedance: | 1 Ohms CT |
| Secondary Impedance: | 1 Ohms CT |
| Isolation Voltage: | 1.5 kV |
| Operating Temperature Range: | 0 C to + 70 C |
| Number of Channels: | Single |
| Product: | LAN |
| Type: | Module |
| Application: | 1000Base-T |
| Length: | 16.51 mm |
| Width: | 9.14 mm |
| Height: | 2.08 mm |
| Packaging: | Bulk |
| Brand: | Pulse |
| Current Rating: | 8 mA |
| Maximum DC Current: | 8 mA |
| Maximum DC Resistance: | 65 mOhms |
| Primary Resistance: | 1 Ohms |
| Product Type: | 1000 Base-T Gigabit Transformers |
| Secondary Resistance: | 1 Ohms |
| LINK-PP Equivalent Part Compatible PN Price |
LP82453NLE Sale / Shop |
