G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer

China G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer supplier
G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer supplier G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer supplier G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer supplier G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer supplier G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer supplier

Large Image :  G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: G5002CG

Payment & Shipping Terms:

Minimum Order Quantity: 200
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock
Payment Terms: T/T, Western Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
Specs: G5002CG P.N China: LP5020NLR
Frequency Range: 1 MHz To 100 MHz Application: Dual 10/100/1000Mbps
Termination Style: SMD/SMT Solation Voltage:: 1.5KV
Samples: Free

G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer



Pin to pin G5002CG  Equivalent Part / Cross Compatible Specification



Electrical Specifications @25℃


1.Insertion Loss:
  1-100MHz:-1.2dB Max
2.Return Loss:
  1-30MHz:-16dB Min
  40MHz:-14dB Min
  50MHz:-13dB Min
  60-80MHz:-12dB Min
3.Crosstalk:
  30MHz:-45dB Min
  60MHz:-40dB Min
  100MHz:-35dB Min
4.Differential to Common Mode Rejection:
  30MHz:-43dB Min
  60MHz:-37dB Min
  100Mhz:-33dB Min
5.Isolation Voltage:1500Vrms
6.Operating Temperature: -40℃~+85℃.

 G5002CG 10/100/1000Base-T Dual Port SMT Magnetic Transformer
